PTFE Tape
PTFE tape is well known as its smooth surface, non-sticky, chemical resistance and high temperature resistance and insulating properties. It is widely used in packaging, heat moulding, laminating, sealing and electrical industries etc. PTFE adhesive tape is enhanced by fiberglass fabric, which improved its tensile strength.It is reusable and easy to change.
In addition, we use excellent imported materials to produce various PTFE adhesive products in different specifications.
Characteristic
1.High temperature resistance. It can work at -70—260℃ continuously.
2.Non-sticky. Its melting remnant is not stick to the heater.
3.Excellent electrical insulation.
4.Good stability and durability.
Application
1.It can be used in hot sealing and cutting machine of food or drug plastic packaging industry and high speed thermal sealing machine.
2.It can be used on the surface of many kinds of machines such as laminating machine drying cylinder, guide roller, paper machine drying cylinder to prevent sticking.
3.It can be used on the face of many tools to prevent sticking to others and dyed or to reduce friction.
Specification
PTFE coated fiberglass adhesive fabric series
Item No. | Thickness (mm) |
Max width (mm) |
Adhesive strength (to steel) (N/100mm) |
Strip strength (N/100mm) |
Temperature ( ℃) |
F7008 | 0.08 | 1250 | 22 | 900 | -70-260 |
F7013 | 0.13 | 1250 | 28 | 1700 | -70-260 |
F7018 | 0.18 | 1250 | 48 | 2750 | -70-260 |
F7025 | 0.25 | 1250 | 62 | 3650 | -70-260 |
Pure PTFE adhesive tape
Item No. | Thickness (mm) |
Max width (mm) |
Adhesive strength (to steel) (N/100mm) |
Strip strength (N/100mm) |
Temperature (℃) |
FS7005 | 0.05 | 1000 | 20 | 200 | -70-260 |
FS7013 | 0.13 | 1000 | 25 | 400 | -70-260 |
FS7018 | 0.18 | 1000 | 44 | 650 | -70-260 |
FS7025 | 0.25 | 1000 | 58 | 950 | -70-260 |
